10.ConnecttheantennacablestothewirelessLANcard.Ensurethatyouattachthegraycabletothemain
connectorandtheblackcabletotheauxiliaryconnectoronthewirelessLANcard.
11.Reinstallthesmallbottomcover1.Thentightenthescrew2.
12.Reinstallthebatterypack.See“Replacingthebatterypack”onpage65.
13.Turnthecomputeroveragain.Connecttheacpoweradapterandallcablestothecomputer.
ReplacingawirelessWANcard
Beforeyoustart,printtheseinstructions.
PrerequisitesforreplacingorinstallingthewirelessWANcard
DANGER
Duringelectricalstorms,donotconnectthecabletoordisconnectitfromthetelephoneoutlet
onthewall.
DANGER
Electriccurrentfrompower,telephone,andcommunicationcablesishazardous.Toavoidshock
hazard,disconnectthecablesbeforeopeningthecoverofthisslot.
Chapter6.Replacingdevices79
