9.Reinstallthelargebottomcover12,andthentightenthescrews3.
10.Reinstallthebatterypack.See“Replacingthebatterypack”onpage65.
11.Turnthecomputeroveragain.Connecttheacpoweradapterandallcablestothecomputer.
ReplacingawirelessLANcard
Beforeyoustart,printtheseinstructions.
DANGER
Duringelectricalstorms,donotconnectthecabletoordisconnectitfromthetelephoneoutlet
onthewall.
DANGER
Electriccurrentfrompower,telephone,andcommunicationcablesishazardous.Toavoidshock
hazard,disconnectthecablesbeforeopeningthecoverofthisslot.
Attention:BeforeyoustartinstallingawirelessLANcard,touchametaltableoragroundedmetalobject.
Thisactionreducesanystaticelectricityfromyourbody.Staticelectricitycoulddamagethecard.
ToreplacethewirelessLANcard,dothefollowing:
1.Turnoffthecomputer;thendisconnecttheacpoweradapterandallcablesfromthecomputer.Wait
threetoveminutestoletthecomputercool.
2.Closethecomputerlidandturnthecomputerover.
3.Removethebatterypack.See“Replacingthebatterypack”onpage65.
76UserGuide
